Weatherproof Isolator Isolation Switch 4 Pole 63A UKF463

Weatherproof Isolator Isolation Switch 4 Pole 63A UKF463

This weatherproof isolator switch is designed for durability and performance, making it ideal for outdoor applications. It operates at 250V and is available in Single and Triple Pole surface mount switches with a 63Amp capacity.

Applications:

• Perfect for isolating Solar jobs, Air Conditioners and other equipment.
• Built to withstand the harsh Australian sun, ensuring long-lasting performance.

Ease of Installation:

• Electricians and air conditioner installers appreciate its user-friendly design.
• Features a neutral link and earth link inside for convenience.
• Equipped with large terminals that can securely clamp down on 6mm to 16mm cables.

Key Features

• Amperage: 63Amp
• IP66 Rated: Provides excellent protection against water and dust ingress.
• Compliance: Meets IEC/EN60947-3 and AS/NZS60947-3 standards.
• Padlocking Facility: Allows the switch to be locked in both ON and OFF positions, adhering to electricity-at-work regulations.
• Durable Construction:
  • Made from high-impact polycarbonate plastic for insulation, strength, and style.
  • Includes a silica gel basket seal between the lid and base for environmental protection.
• Dimensions:
  • Width: 84mm
  • Height: 84mm
  • Length: 174mm.

Additional Benefits

• Weather Protection: Suitable for any external application.
• Versatile Range: Available in 20 Amps, 32 Amps, and 63 Amps for single and triple pole switches.
• Effortless Wiring:
  • Base mount mechanism allows for easier termination and additional wiring room.
  • Fixed Earth and Neutral connector bars with dual clamping screws per tunnel.
  • Insulated caps cover base mounting screws, ensuring protection from live cables.
• Flexible Conduit Entries:
  • Dual 25mm screwed conduit entries at the top and bottom, providing four wiring options.
  • Includes screwed conduit plugs, reducers, and screw caps to maintain IP rating.
• Security: Hole provided for padlocking the lever in the OFF position.
• Impact Resistance: Designed with a robust base and cover to withstand tough conditions.
• Utilisation Category: AC22A, AC23A.

This isolator switch combines robust construction, ease of use, and compliance with safety standards, making it a reliable choice for professional installations.
