Weatherproof Isolation switch Isolator 2 pole 35A UKF135

Weatherproof Isolation switch Isolator 2 pole 35A UKF2P35A

Weather Proof Isolator switches are designed for external applications, offering reliable performance in challenging conditions. Available in Double and Triple Pole surface mount switches with a voltage rating of 250V and up to 63Amp capacity.

Key Features:

• Weather protected design: Suitable for any external application.
• Range options: Double and triple pole switches available in 20 Amps, 32 Amps, and 63 Amps.
• Ease of wiring:
  • Base mount mechanism provides more wiring room and easy termination.
  • Fixed Earth connector bars with dual clamping screws per tunnel.
• Safety enhancements:
  • Insulated caps cover base mounting screws to protect from live cables.
  • Dual 25mm screwed conduit entries (top and bottom) allow four ways to surface wire the switch.
• Convenient installation:
  • Each unit comes with screwed conduit plugs, screwed reducers for easy connection to 25mm or 20mm conduits, and screw caps. Screw caps must be installed to ensure the IP Rating.
• Security feature: Includes a hole for padlocking the lever in the OFF position.
• Durability: Impact-resistant base and cover designed to withstand the hardest knocks in almost any installation.
• Utilisation categories: Rated for AC22A and AC23A.

This isolator switch is engineered for robust performance and safety, ensuring reliable operation in demanding environments.
