Hager 32A 2 pole RCBO type A 6kA ADA932T

Hager 32A 2 pole RCBO type A 6kA ADA932T

It is 2 pole RCBO is a C Curve safety switch all in one unit. It has a 6kA rating ideal for commercial and residential applications. The RCD/MCB combo will protect property and life should current be detected leaking to earth within 30mA. The switch has an inbuilt test switch and is easily reset after the fault is rectified.

This is generally installed on 1 phase circuits to protect motors, appliances and control equipment.

Features

Breaking Current 6 kA
Number of modules 2
Number of poles 2 P
Curve C
Rated operational AC voltage 240 V
Rated residual operating current 30 mA
Residual current type A
Frequency 50 Hz
Rated insulation voltage 500 V
Rated impulse withstand voltage 4000 V
Operating temperature -25 to 40 °C
Electric endurance in number of cycles 2000
Number of mechanical operations 2000
Connection cross-sect. rigid cable 1 / 25mm²
Connection cross-sect. flexible cable 1 / 16mm²
Tightening torque 2,1Nm
Height of installed product 83 mm
Width of installed product 35 mm
Depth of installed product 68 mm
