Hager 16A 4 pole Type A RCBO ADM416T
SKU HAG-ADM416T
$140.89
On Sale
was $180.89 Save $40.00
In stock
1
Save this product for later
Hager 16A 4 pole Type A RCBO ADM416T
Product Details
Brand: HAGER
Weight: 0.45 kg
Hager 16A 4 pole Type A RCBO ADM416T
The Hager 4 pole RCBO is a C Curve safety switch all in one unit. It has a 6kA rating, making it ideal for both commercial and residential applications. The RCD/MCB combo is designed to protect property and life by detecting current leakage to earth within 30mA. Additionally, the switch features an inbuilt test switch and can be easily reset once the fault is rectified.
This RCBO is typically installed on 3 phase circuits, such as motors, appliances, and control equipment.
Key Features:
- 10 Amps
- Breaking Current: 6kA
- Number of modules: 4
- Number of poles: 4 P
- Curve: C
- Rated operational voltage Ue: 240/415 V
- Rated residual operating current: 30 mA
- Residual current type: A
- Frequency: 50 Hz
- Rated insulation voltage: 500 V
- Rated impulse withstand voltage: 4 kV
- Operating temperature: -25 to 40 °C
- Electric endurance: 2000 cycles
- Number of mechanical operations: 4000
- Tightening torque: 2Nm
- Dimensions:
- Height: 84 mm
- Width: 71 mm
- Depth: 70 mm
- Fixing mode: Din-Rail
- Standard compliance: IEC 61009-1; AS/NZ 61009-1
