Hager 16A 3 pole Circuit Breaker MCB 6kA MSN316

Hager 16A 3 pole Circuit Breaker MCB 6kA MSN316

This is a three pole circuit breaker designed to protect and control circuits against overloads and short-circuits. Rated at 6kA, it is suitable for both commercial and domestic applications.

Key Features:

• 3 Pole
• 6KA Circuit Breaker
• Number of modules: 3
• Rated short circuit breaking capacity: 6 kA
• Curve: C
• Frequency: 50/60 Hz
• Rated insulation voltage: 500 V
• Operating temperature: -25 to 60 °C
• Electric endurance in number of cycles: 4000
• Number of mechanical operations: 20000

Connection Specifications:

• Top and bottom screw terminals connection capacity with rigid cable: 1/25 mm²
• Top and bottom screw terminals connection capacity with flexible cable: 1/16 mm²
• Tightening torque: 2.8 Nm

Dimensions:

• Height of installed product: 83 mm
• Width of installed product: 52.5 mm
• Depth of installed product: 70 mm
