Eaton Quicklag 10A RCBO Earth Leakage Breaker 1 pole 30mA ELQ110C3TD

Eaton Quicklag 10A RCBO Earth Leakage Breaker 1 pole 30mA ELQ110C3TD

The ELQ breaker (safety switch) is a compact unit that combines overload, short circuit, and residual current protection (earth leakage) in a single pole configuration. This type of circuit breaker, now mandatory in new installations, is designed to safeguard people from the dangers of electric shock. It works by instantly interrupting the electrical circuit to the load whenever a fault current to earth exceeds the rated sensitivity, typically expressed in milli-Amps (mA).

Features at a glance:

• Combined MCB/RCD device
• Permanent connected neutral conductor (950mm)
• Rating breaking capacity: 6kArms
• Compliance: AS/NZS 3190:2016 and AS/NZS 3111:2009+A1-2
• Australian approval number: NSW27675
