CLIPSAL 32A RCBO 1P+N 30mA RCBE232/30S

CLIPSAL 32A RCBO 1P+N 30mA RCBE232/30S

Clipsal Resi Max RCBO is a Residual Current Breaker with Overcurrent Protection.
The product was designed to meet new wiring regulations to minimise injuries related to electric shock.
The slimline device is also commonly referred to as a single pole combo and was developed to maximise space in domestic switchboards and load centres.
The Clipsal 32 Amp Rcbo also saves time and money on installation. As both line and load terminals are non sensitive, rewiring is not required if replacing an alternative brand.

This is a single pole MCB/RCD combination - It only takes up the space of 1 module in a switchboard or sub board.
The RCBE232/30S RCBO can be wired from the top or bottom.


Features:

Residual current breaker with overcurrent protection (RCBO)
Product brand: Clipsal
Poles description: 1P + N
Neutral position: Left
Number of protected poles: 1
[In] rated current: 32 A
Trip unit technology: Thermal-magnetic
Curve: C
Earth-leakage sensitivity: 30 mA
Earth-leakage protection class: Type A
Breaking capacity: 4.5 kA Top and bottom, line and load compatible
Narrow module design, allows for more RCDs/MCBs to be installed in the one enclosure
Compatible with Clipsal switchboards and switchboard accessories
AS/NZS 61009 compliance
Two–year warranty.
