3 Pole 20A Weatherproof Isolation Switch Isolator TESTWIS3P20L

3 Pole 20A Weatherproof Isolation Switch Isolator TESTWIS3P20L

Description -

Weatherproof Isolator Switches, 250V in Single and Triple Pole surface mount switches, available in 20Amp, 32Amp, and 63Amp.

Features -

• Weather protected isolating switches, suitable for any external application.
• Range includes single and triple pole switches in 20 Amps, 32 Amps, and 63 Amps.
• Easily terminated with more wiring room, thanks to the base mount mechanism.
• Fixed Earth and Neutral connector bars with dual clamping screws per tunnel for secure connections.
• Insulated caps cover base mounting screws to protect against live cables.
• Dual 25mm screwed conduit entries at the top and bottom, allowing four ways to surface wire the switch.
• Each unit comes with:
  • Screwed conduit plugs.
  • Screwed reducers for easy connection to 25mm or 20mm conduits.
  • Screw caps, which must be installed to maintain the IP Rating.
• Security feature: A hole provided for padlocking the lever in the OFF position.
• Impact-resistant base and cover, designed to withstand the hardest knocks in almost any installation.
• Utilisation categories: AC22A, AC23A.

This isolator switch combines durability, functionality, and security, making it ideal for demanding external applications.
